Electric Chain Hoist
N series
Load Chain
Japanese-made grade 80 super alloy steel, heat-treated chain is suitable for applications in harsh operating environments.
Hook
-
Hot-forged, excellent strength and toughness
-
Bottom hook swivels through 360 degrees.
-
Safety catches on top and bottom hooks
Power supply
3 phase 220V-600V
Load Supporting Frame
Chain wheel case, gear case B and load-supporting frame are constructed with one piece of FCD45 nodular cast-iron.
Motor brake
Fast-acting magnetic brake (ROC New Design Patent No. 45572) cuts in when power supply is interrupted.
Slip Clutch
The slip clutch well performs the functions of
overload protection.
Without limit switch and limit spring, it offers utmost lifting space.
48V Controller Voltage
48V controller can prevent personnel from injury caused by current leakage of push button control unit.
Simple parts and less maintenance.
N series
